ELMOFO 24V 100Ah 2.59kWh Lithium Battery Module

Be the first to review this product

Availability: In stock


Quick Overview

Pack Voltage (Nom):   25.9V
Pack Capacity:   100Ah
Pack Energy:   2.59kWh
Discharge Current:        350A 20sec
Pack Weight:   16.65kg

Cost effective High Power Lithium Battery modules suitable for Remote Solar, Industrial Energy Storage and Telecommunications Sites

ELMOFO 24V 100Ah 2.59kWh Lithium Battery Module

Double click on above image to view full picture

Zoom Out
Zoom In

More Views


Suitable for a variety of applications including recreactional and industrial power systems.

These 24V 100Ah 2.59kWh ELMOFO Lithium Battery Packs were designed to enable a simple and effective upgrade from lead-acid batteries in a wide variety of applications.

ELMOFO ESB Lithium Battery Packs utilise the ELMOFO 50NMC Powercells. These are CALB's A-Grade NMC Lithium Ion cells and are capable of more than 2000 cycles to 80% Depth of Discharge.

Capacity:   2.59kWh (100Ah)
Voltage (Nom):   25.9V
Voltage (Max):   29.4V
Voltage (Min):        23.0V
Discharge Current (Peak):   350A (BMS Limit)
Discharge Current (Cont):   200A (BMS Limit)
Charging Current (Max):   100A
Enclosure Dimensions:   270 x 160 x 270mm
Unit Weight:   16.65kg

These Lithium modules feature: applications that require:

• High power output
• Long battery life
• Excellent energy density

Other applications include:

• Energy storage for remote solar installations
• Remote radio and telecommunications sites
• Peak load shaving on domestic, commercial and industrial sites
• Battery backup for remote water pumping
• Solar lighting systems
• Mining and other industrial applications
